HD2 Series Humidity Sensors - Analog - Installation Guide
HD2 Analog Series Humidity Transmitters provide an ideal solution for measuring relative humidity in a wide range of conditions. All models are equipped with a solid state capacitive humidity sensor that is easy to replace in the field and a solid state temperature sensor for high accuracy measurements. HD2 is an all-in-one device combining humidity and temperature sensing. Intended for duct mount applications, the device ensures a building’s optimum temperature and humidity levels, resulting in greater energy efficiency. Each device is an active sensor that converts a humidity or temperature measurement into 4-20 mA, 0 to 5 Vdc or 0 to 10 Vdc analog output. Different models are available based on application requirements for lower-cost installations.
Date:
Sep 16 2024| Type:
Instruction sheet
Languages:
English| Version:
01
Document Number:
GEX55252
Files
File Name
HD2 Analog_GEX55252-01.pdf
Related products
Product Ranges:
Humidity Sensors
