Line side electrical and arc isolation for motor control centers and switchboards

ArcBlok™ is designed with features that help avoid an arc flash before it happens. Barriers keep foreign objects, such as a hand, a dropped nut or screwdriver from entering the energized line side. Sensors inside the compartment continuously take thermal readings and communicate those to a mobile device, while maintenance personnel stand outside the arc flash zone to review.

Arc Resistant LVMCC - Enhanced arc flash safety design Model 6 - AR Motor Control Centers provide additional levels of arc flash prevention and minimizes the potential for personnel injury by containing and redirecting the arc energy.

Intelligent Motor Control Center (NEMA, ANSI, UL 845) Model 6 iMCC delivers Integrated intelligent components and device-level communications for hardwired I/O or networked control and automation solutions.

Intelligent Motor Control Center Design Support Model 6 iMCC design support is an exclusive resource that empowers Square D customers to achieve success by providing solutions and tools that help save time and money.

Native solution for integrating the Model 6 iMCC with energy monitoring, automation and control infrastructures This Model 6 intelligent motor control center (iMCC) solution provides a tested and validated architecture for system integration, reducing project engineering, minimizing risk, and creating seamless setup time within the project execution lifecycle. Templates are designed to provide recommendations, guidelines, examples and performance measurements to help system integrators design their high dependability iMCC architecture.

(CDR) Closed Door Racking Solution The Model 6 +CDR feature allows the user to safely engage and disengage power stabs from the vertical bus with the unit door closed.

Standard & Industrial LVMCC (NEMA, ANSI, UL 845) Model 6 MCCs offer an efficient, economical solution for grouping electrical motor control, automation and power distribution in a compact design that meets industry safety standards.

RapidSource Ready to Wire Motor Control Center

RapidSource RTW MCCs provide full, flexible, and fast access to a broad array of configurations and components. SE AdvantageTM digital tools, coupled with our premier industry support team, make it easy for you to create your design and gain access to unique, state-of-the-art technologies.
